You see it often in Levis — the fine alluvial and deltaic sands deposited by the St. Lawrence River that look stable on the surface but can behave very differently during a seismic event. When the ground shakes, loose saturated sands can temporarily lose all shear strength, turning into a heavy fluid that can no longer support structures. This is liquefaction, and it is one of the most dangerous geotechnical failure modes for projects built on river terraces or reclaimed land. Our team brings field testing and laboratory analysis together under NBCC 2020 seismic provisions to quantify this risk before you commit to foundation design. For sites with marginal soil conditions, we often pair the liquefaction assessment with a CPT test to get a continuous profile of tip resistance and sleeve friction without disturbing sensitive sand fabric.

Liquefaction doesn't just cause bearing failure — it can trigger lateral spreading toward the river, and in Levis that means metres of permanent ground displacement.

Process and scope

The geological setting of Levis, with its St. Lawrence lowlands soils, means we are frequently dealing with clean to silty sands with groundwater within 2 to 4 metres of grade. This is exactly the profile where cyclic mobility can occur under the design earthquake specified in the NBCC for the Charlevoix seismic zone. Our analysis follows the simplified procedure developed by Seed and Idriss (1971) and updated by Youd et al. (2001), which correlates standardized blow counts or CPT data with cyclic stress ratio and fines content. Where the site investigation reveals stratified deposits, we combine the analysis with a grain size distribution test to calibrate the liquefaction susceptibility curve. All laboratory work runs under our ISO 17025 accredited system, so you get defensible numbers for regulatory submissions.

Local ground factors

Compare two sectors in Levis: the older, elevated terraces near the historic district versus newer residential fills along the Chaudière River flats. On the terrace, dense glacial till provides a natural buffer against liquefaction even under strong shaking. Down on the river flats, thick sequences of Holocene sand with a shallow water table can liquefy at PGA values as low as 0.15g, which is well within the design earthquake for the region. The real danger isn't just bearing capacity loss — it's lateral spreading toward the river channel, which can pull apart underground utilities and shift foundations irreversibly. A post-liquefaction settlement analysis following Ishihara and Yoshimine (1992) often reveals that a moderate event could produce 50 to 150 mm of differential settlement, enough to render a building unsafe without ground improvement.

Technical data

Parameter	Typical value
Standard evaluated (NBCC 2020)	Division B, Part 4 seismic provisions
Analysis method	Simplified Seed-Idriss (NCEER/Youd 2001)
Field test inputs	SPT N60, CPT qc/fs, shear wave velocity Vs
Fines content correction	Laboratory grain size (ASTM D422)
Cyclic stress ratio (CSR)	Computed for M7.5 reference, depth-adjusted
Factor of safety against liquefaction	FSL ≥ 1.2 for design acceptance
Post-liquefaction settlement	Ishihara & Yoshimine volumetric strain method
Lateral displacement potential	Newmark sliding block or empirical approach

Related services

Liquefaction Triggering & Settlement Analysis

Full assessment of cyclic stress ratio vs. cyclic resistance ratio using SPT or CPT data, with post-liquefaction volumetric strain computed per Ishihara and Yoshimine. We deliver factor-of-safety maps by depth and settlement predictions for foundation design.

Lateral Spreading & Ground Improvement Assessment

Evaluation of lateral displacement potential for sites near the St. Lawrence or Chaudière River slopes, including pre- and post-improvement analysis for techniques such as vibrocompaction, stone columns, or deep soil mixing to mitigate liquefaction risk.

Applicable standards

NBCC 2020 (National Building Code of Canada, seismic provisions), CSA A23.3:2019 (Design of concrete structures, seismic requirements), ASTM D6066 (Standard Practice for Determining the Normalized Penetration Resistance of Sands for Evaluation of Liquefaction Potential), ASTM D5778 (Standard Test Method for Electronic Friction Cone and Piezocone Penetration Testing of Soils), Youd, T.L. et al. (2001) NCEER/NSF Workshop on Evaluation of Liquefaction Resistance of Soils

Frequently asked questions

What does a soil liquefaction analysis cost for a typical Levis residential or commercial lot?

For a standard lot in Levis, a complete liquefaction triggering and settlement analysis generally runs between CA$3,710 and CA$5,840, depending on whether we are working with existing SPT/CPT data or need to plan and execute a new field investigation. The cost covers data reduction, fines content correlation, CSR/CRR computation, post-liquefaction settlement modeling, and a stamped engineering report.

Is liquefaction a real risk in Levis, or is it only a concern near Vancouver and the West Coast?

Absolutely a real risk here. The Charlevoix Seismic Zone, just northeast of Quebec City, is one of the most active in Eastern Canada, with a history of magnitude 6+ events. Levis sits on St. Lawrence alluvial deposits — loose sands with high groundwater — which are precisely the materials that can liquefy. The NBCC 2020 assigns a non-negligible seismic hazard to this region, and ignoring liquefaction on a river-flat site is a serious design error.

How do you determine if my soil is susceptible to liquefaction?

We start with the grain size distribution from laboratory testing under ASTM D422. Susceptible soils are typically clean to silty sands with less than 15% fines and a uniformity coefficient below 5. Then we use in-situ test data — SPT blow counts or CPT tip resistance — to compute the cyclic resistance ratio and compare it with the earthquake demand. A factor of safety below 1.2 triggers a recommendation for ground improvement or deep foundation alternatives.
